Private wireless peer: #1 – first steps

Recently I’ve grown the requirement for on-demand bandwidth in both ways to a friend. Both our regular consumer internet connections are rather limited. They have a bandwidth cap on 200 Mbps down and 12 Mbps up. That’s not too bad, but they are both in use all the time and thus limiting the available bandwidth. So we started analysing the available and affordable options.

As we do live in the same village on a distance of about 500 meters, we concluded that a private peering by a wireless point-to-point connection is a feasible option.

Line of sight

The first thing we did was look at pictures that recently were taken on the roof on one of the locations and it was quite obvious that a clear line of sight wasn’t possible. One of the locations is surrounded by trees. Somewhat better is the fact that the tree line is quite thin in that direction.

google-maps-distance

I was in contact with petzl. He’s a community member of userbase.be and one of the administrators of Wireless Belgium. I was very interested to connect to their network and he would happily come by my house to measure if I could receive their network signal on my location. More on that network later.

He came prepared, to say the least. He had a mobile pillar that could easily go up to 15 meters. He attached a directional 5 Ghz antenna and pulled the pillar up next to my house and scanned the ether looking for one of their nodes a few kilometres away. He did the same at my friend’s place.

IMG_20150717_215906

We took advantage of the moment to test the connection between our houses. He gave me a smaller extendible pillar that I could hold by hand with a omnidirectional 5 Ghz access point attached. Whilst I was waving at my house with the mobile pillar he was scanning the ether at my friend’s house.

He was able to get a signal of -78 dBm. There was a single tree in between which affected the signal level. We had a feeling that we could overcome this by using directional antenna’s on both ends, so we went on with our small project.

Hardware

A few tips we had from Petzl was to use the 5 Ghz band and an Ubiquiti PowerBeam M5-300. The M5-300 is a 5 Ghz directional antenna with a 30 cm dish and a built-in access point. The 2.4 Ghz band is really polluted and shouldn’t be trusted for ‘long’ distance connections, that’s the main reason to use 5 Ghz.

51rDKqW05uL._SL1046_

We ordered some antenna mounts as well from a specialised web shop. You can really find anything on the internet these days.

To manage the routing for our internet uplinks and the private peer we use a Mikrotik RB2011UiAS-2HnD-IN. I already had one in service for quite some years as I avoid consumer gateways. Those are unstable, limited and really expensive. It really baffles me that vendors can get away with it.

682_l



This router supports anything you need or want to experiment on at home for a reasonable price.

Continue reading in part #2 soon.

Tweet about this on TwitterShare on Google+Share on FacebookShare on LinkedInEmail this to someoneShare on Reddit
Feel free to share ...

Use a disk on the Audi Music Interface

Quite recently my Audi A3 8V Sportback was delivered. Great!

Audi A3 8V

Driving it has been a delight so far. One of the reasons why is the fact that all my music is available to play on the Audi Sound System. Chills guaranteed!

There’s the possibility to add 2 SD cards and the Audi Music Interface cable allows you to connect USB storage. During the order process it stated that the SD card readers only supports up to 32 GB and it didn’t state anything on limitations for the USB storage.

Audi Music Interface

I still had an old Western Digital Passport 320 GB drive. It uses a single USB connector for data throughput and power. It spins up, great! From what I’ve found it can deliver 500 mA of power for your drive.

And now, for accessing the data volume: after some trial and error I came to the conclusion that NTFS formatted volumes aren’t supported, but the good old FAT32 is!

The next hassle is the fact that since Windows XP the built-in format tool only allows to create 32 GB FAT32 volumes. I’ve learned that FAT32 supports up to 2 TB volumes. It doesn’t make sense why the limitation is present.

Of course you are not obliged to use the built-in format tool. I’ve found another one named FAT32 Formatter. The website gives clear instructions on how to make a volume as you wish.

Once you’ve done this, simply copy all your music to the drive and connect it to the Audi Music Interface. And there you go! Forget about the 32 GB volume limit, up to 2 TB of music is at your expense this way.

On a sidenote: it’s possible to use SD cards up to 2 TB if you order the GPS Plus with MMI touch navigation system. Only issue with that is that it costs 130% more than the GPS with SD card option. Unless you have an unlimited budget …
